ANNKE 8CH Wired Outdoor Security Camera System with AI Human/Vehicle Detection, 4K H.265+ 5-in-1 DVR and 4x2MP Cameras, Email Alert with Snapshots, 0TB HDD, 66ft Night Vision, Smart Dual Light

<p><b>Description:</b></p> <p><b>DVR </b></p> <p>· 4K(8MP) high definition live viewing · 4K(8MP) recording &amp; playback </p> <p>· Deep learning-based motion detection 2.0 for all analog channels </p> <p>· Deep learning-based perimeter protection</p> <p>· Advanced H.265+ Video Compression</p> <p>· Aduio via coaxial cable</p> <p>· Support TVI/AHD/CVI/CVBS/IPC input. 5 in 1 </p> <p>· Supports iPhone、iPad、Android mobile remote monitoring</p> <p>Video &amp; Audio </p> <p>Video Compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264</p> <p>Video Input: "8CH Analog HD/Analog + 4CH (up to 12-ch) IP (Enhanced IP mode on:</p> <p>8-ch (up to 16-ch), each up to 4 Mbps)"</p> <p>Video Output: VGA up to 1080p/60 Hz; HDMI up to 4K (3840 × 2160)/30 Hz</p> <p>Audio Input/Output: "Input: 1-ch, RCA (2.0 Vp-p, 1 KΩ)/8-ch via coaxial cable</p> <p>Output:1-ch, RCA (2.0 Vp-p, 1 KΩ)"</p> <p>Supported Camera Types: "Support HD TVI Input: 8 MP@15 fps, 5 MP@20 fps, 3K@20 fps, 4 </p> <p>MP@30 fps, 4 MP@25 fps, 3 MP@18 fps,</p> <p>1080p@30 fps, 1080p@25 fps, 720p@60 fps, </p> <p>720p@50 fps, 720p@30 fps, 720p@25 fps</p> <p>Support AHD Input: 5 MP@20 fps, 4 MP@30 fps, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps;</p> <p>Support HD CVI Input: 4 MP@30 fps, 4 MP@25 fps, 1080p@25 fps, 1080p@30 fps, 720p@25 fps, 720p@30 fps;</p> <p>Support CVBS Input:PAL/NTSC"</p> <p>Analog HD Playback Resolution: "4K@8 fps/5MP@12 fps/4MP@15 fps/3MP@18 fps</p> <p>1080p/720p/WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N)"</p> <p>IP Camera Input: 4-CH (up to 12-ch)</p> <p>IPC Recording Resolution: Up to 8MP</p> <p>IPC Playback Resolution: Up to 8MP</p> <p>Max Playback Channel: 8CH </p> <p>Motion Detection 2.0: Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights.</p> <p>Smart event: Line crossing &amp; Intrusion Detection</p> <p>ONVIF: Support</p> <p>Hard Drive</p> <p>HDD: 1 SATA Interface</p> <p>HDD Capacity:Up to 10 TB Capacity</p> <p>General</p> <p>Working Temperature: 14 °F – 131 °F/-10 °C – 55 °C</p> <p>Dimensions (W X H X D): 315 X 242 X 45 mm</p> <p>Weight (Without Hard Disk) : ≤ 2 kg (4.4 lbs.) (Without HDD)</p> <p><b>Analog HD Camera </b></p> <p>"High quality imaging with 2 MP, 1920×1080 resolution </p> <p>3.6 mm fixed focal lens</p> <p>Up to 20 m IR distance for bright night imaging</p> <p>Up to 20 m white light distance for bright night imaging</p> <p>Water and dust resistant (IP67) "</p> <p>Image sensor: 2MP CMOS Image sensor</p> <p>Video Resolution: 1920 (H) × 1080 (V)</p> <p>Signal System: PAL/NTSC</p> <p>Frame Rate: "TVI: 1080P @ 30 fps, 1080P @ 25 fps</p> <p>Lens:3.6mm</p> <p>Min.Illumination: Color:0.01 Lux @ (F1.2,AGC ON),0 Lux with IR</p> <p>Angle of View: Horizontal FOV: 78°, vertical FOV: 42°, diagonal FOV: 92°</p> <p>Supplement Light type: White Light &amp; IR</p> <p>Supplement Light Range:IR : Up to 20 m, white Light : Up to 20 m</p> <p>Supplement Light Mode:IR light works normally, and it switches to white light when human or vehicle are detected at night.</p> <p>Wide Dynamic Range:Digital WDR</p> <p>IR Cut Filter:Yes</p> <p>Video Output: BNC, switchable TVI/AHD/CVI/CVBS</p> <p>General </p> <p>Housing:Metal&amp;Plastic </p> <p>Color:Black</p> <p>Operating Power: DC12V</p> <p>Operating Temperatur: -40 °F – 140 °F /-40 °C – 60 °C</p> <p>Indoor/Outdoor: Indoor/Outdoor</p> <p>Weatherproof Rating: IP67</p> <p>Dimension (L x W x H): Ø85 mm × 84.6 mm(3.35" × 3.33 ")</p> <p>Weight: Approx. 205 g (0.45 lb.)</p>

• 1： Innovative Human & Vehicle Detection – By setting up the human & vehicle detection, you will get motion detection alerts only when people and vehicles are in the frame. Minimizing unwanted alerts triggered by bugs, animals, leaves and so on.
• 2：1080p Wired Security Cameras & 8 Channel DVR – 4 pcs security cameras deliver the best 1080p live view at 30 fps & up to 100 ft night vision. The advanced sensor & smart IR help capture clear images without noise. The 5-in-1 5MP Lite DVR works with TVI, AHD, CVI, CVBS & IP cameras.
• 3：All-Around Certifications & Secure App – Every device, including the DVR & cameras, passed the severe testing conducted by authorized organizations, like UL, CE, etc. ANNKE App conforms to GDPR, ensuring the video stream is secure in data transferring & downloading.
• 4：Advanced H.265+ Video Format – H.265+ coding reduces the file sizes and saves the bandwidth greatly. You'll enjoy a faster & smoother live stream than H.264 systems, without buffering or latency.
• 5：The housing, made from the best ABS materials, provides fast heat dissipation & a long lifespan without fading.
